Humphree
Interceptor

The X-Series is meant for boats from 25 up to 60 feet. The four sizes, X300, X450, X600 and X750 are all available with the powerful 50mm (2”) stroke needed for excellent control of dynamic hull motions. The X-Series delivers the same reliability and superior performance as the other Humphree interceptors however, the range is limited to four standard sizes. The X-Series features the same control system, ultra-fast servo actuators and control panel. For boats with stern drive a special “13 degree” mounting plate is available in order to
have a perfect fit.

•     Available sizes: 300 – 750mm
•     Stroke length: 50mm
•     Mounting plates: 20mm composite or 20mm aluminum
•     Transom thickness:
            Short shaft kit (standard), <80mm transom thickness.
            Long shaft kit (option), <140mm transom thickness
•     Bureau Veritas approved through-hull design

H-Series are available from 350 – 1500 mm in width. H-Series characterizes a customizable interceptor. We can customize its shape for the hull and make it fit under your water jet, a perfect fit at the shine, or make it follow the radius of the propeller tunnels. No matter the hull’s design, there is always a solution.

•      Available sizes: 350 – 1500mm
•      Stroke length: 50mm
•      Mounting plates: 20mm composite or 25mm aluminum
•      Transom thickness:
              Short shaft kit (standard), <80mm transom thickness.
              Long shaft kit (option), <140mm transom thickness
•      Bureau Veritas approved through-hull design

HA-Series is our line of interceptors that has an asymmetric placed servo unit. This interceptor can be used when it must be under a water jet or if preferred area of the transom is limited for when the inner structure on the inside of the transom does not allow for a center placed servo. The HA-interceptor comes in sizes 500 – 1100mm and can be customized for a perfect fit.

Available sizes: HA500 – HA1100 (50mm stroke, asymmetric)
•      Available sizes: 500 – 1100mm
•      Stroke length: 50mm
•      Mounting plates: 20mm composite or 30mm aluminum
•      Transom thickness:

Short shaft kit (standard), <80mm transom thickness.
Long shaft kit (option), <140mm transom thickness
•      Bureau Veritas approved through-hull design

HE-Series
The HE-Series interceptors have been designed for heavy duty use. With their powerful 75mm stroke length they add 50% more lift force than the standard 50mm interceptors. The HE-interceptor comes in sizes 750 – 1500mm and can be custom shaped for a perfect fit.

•      Available sizes: 750 – 1500mm
•      Stroke length: 75mm
•      Mounting plates: 20mm composite or 30mm aluminum
•      Transom thickness:

Short shaft kit (standard), <80mm transom thickness.
Long shaft kit (option), <140mm transom thickness
•      Bureau Veritas approved through-hull design

Our HL-Series are designed and built for the large and heavy planning vessels. With its mechanically high performing structure, the HLS-interceptors blade has a powerful 110mm stroke length. The HLS interceptor is available from 800mm to 1500mm width.

•      Available size: 800mm – 1500mm
•      Stroke length: 110mm
•      Servo unit: SU530
•      Mounting plates: Integrated in interceptor structure
•      Transom thickness: 8-32mm (steel, aluminum)
